Full Automatic Die Cutting Machine
Models: EC-1300 / 1450 / 1620 / 1670 / 2100Q
Corrugation Die Cutting Machines
Full Automatic Die Cutting Machine with Stripping — Corrugation
Models: EC-1300 / EC-1450 / EC-1620 / EC-1670 / EC-2100Q
Cassette/Lead edge/Bottom Suction feeder automatic die cutting with stripping for corrugated cardboard packaging production.
Product Overview
Engineered for Excellence
The EC-1300/1450/1620/1670/2100Q series by Eureka Machinery (Member of GW Group) is a full automatic die cutting machine specifically designed for corrugated cardboard and heavy paperboard. The machine offers three feeding configurations — cassette, lead-edge, and bottom suction — to handle diverse substrates. A computerised 3D touch screen provides real-time machine status and error identification. The integrated stripping section uses double-action upper/lower frames with front, back, left, and right stripping functions to minimise downtime and ensure clean sheet separation. The delivery section uses a pallet collection system with photoelectric detection for smooth, steady output.
Key Features
Advanced Capabilities
Three Feeder Configurations
Cassette, lead-edge, and bottom suction feeder options to match different corrugated substrates and weights.
3D Touch Screen Control
Computerised 3D touch screen for instant machine status reading, error identification and parameter control.
Automatic Stripping Section
Double-action upper/lower stripping frames with front/back/left/right functions minimise downtime.
Pallet Collection Delivery
Flexible pallet collection delivery with photoelectric detection for smooth, steady sheet delivery.
Up to 500 Tons Pressure
EC-2100Q delivers 500 tons cutting pressure for the heaviest corrugated and multi-ply substrates.
Auto Arc-Prefeeder Option
Optional HSL 1650/2400 automatic and BSL 1650 semi-automatic arc-prefeeders for non-stop feeding.
Technical Specifications
Technical Parameters
| Parameter | EC-1620Q | EC-1670Q | EC-2100Q |
|---|---|---|---|
| Feeding type | Lead edge / Cassette / Bottom feeder | Lead edge / Cassette / Bottom feeder | Lead edge / Cassette / Bottom feeder |
| Max. paper size | 1650×1210mm | 1670×1260mm | 2200×1520mm |
| Min. paper size | 650×500mm | 650×500mm | 800×600mm |
| Max. cutting size | 1620×1190mm | 1640×1230mm | 2180×1510mm |
| Max pressure | 350 Tons | 400 Tons | 500 Tons |
| Substance scope | 1 ≤ Flute ≤ 8.5mm | 1 ≤ Flute ≤ 8.5mm | 1 ≤ Flute ≤ 8.5mm |
| Accuracy | ±0.5mm | ±0.5mm | ±0.5mm |
| Max mechanical speed | 5200s/h | 5500s/h | 4500s/h |
| Cutting rule height | 23.8mm | 23.8mm | 23.8mm |
| Pressure adjustment scope | ±1mm | ±1.5mm | ±1mm |
| Min. front margin | 8mm | 10mm | 10mm |
| Inner chase size | 1646×1220mm | 1680×1260mm | 2110×1524mm |
| High pile Delivery height | 1390mm | 1400mm | 1300/450mm |
| Delivery method | High pile / batch delivery | High pile / batch delivery | High pile / batch delivery |
| Main motor power | 18.5kw | 22kw | 30kw |
| Total power | 37kw | 44kw | 60kw |
| Size (Without platform) | 9500×5354×2687 | 10360×5400×3000 | 12500×6930×2850 |
| Size (With platform) | 8350×3200×2687 | 9260×3100×3000 | 11310×3900×2850 |
| Total weight | ≈32t | ≈35t | ≈52t |
Use Cases
Applications
- Corrugated Box Manufacturing
- Heavy-Duty Packaging
- Food & Beverage Boxes
- Industrial Packaging
- E-commerce Packaging
